| 交流输入电压范围 |
|
| AC input voltage range |
170～264VAC |
| 直流可调范围内 |
输出电压的±10% |
| DC adjustment range |
±10% of rated output voltage |
| 过载保护 |
105%～150%过电流限制. |
| Over load up protection |
105%～150% hiccup mode, auto-recovery |
| 过压保护 |
|
| Over voltage protection |
115%～135% of rated output voltage |
| 起动,上升,保持时间 |
|
| Setup, rise, hold up time |
1000ms, 30ms, 15ms at full load and 230VAC |
| 耐压性 |
|
| Withstand voltage |
I/P-O/P:3KVAC, I/P-FG:1.5KVAC for 1 minute |
| 工作温度,湿度 |
|
| Working temperature |
0～45℃@100%, -10℃@80%, 60℃@60% load |
| 安全标准 |
|
| Safety standards |
UL1012, UL1950, TUV EN60950 approved |
| EMC标准 |
EN55022 class B, EN61000-3-2, 3, |
| EMC standards |
EN61000-4-2,2,3,4,5,6,8,11,ENV50204 |
